FIBER OPTIC INSTRUMENTS
FIELD OPTICAL SOURCE
An optical source is an instrument that emits light through a diode or LED at a predetermined wavelength with maximum stability over time in order to measure the optical power and the relative attenuation through an optical power meter or power meter positioned at the other end of the network.
The measuring instrument is able to operate in 4 different wavelengths and can be used in applications with single-mode and multi-mode optical fiber.
OPT-POW-MET-01 / Highly stable field light source supporting two wavelengths @1310nm and @1550nm
| TECHNICAL FEATURES | |
|---|---|
| WAVELENGHT | 1310/1550 nm |
| SOURCE / DETECTOR | FP-LD |
| POWER | > -5 dBm @ 1310/1550nm frequency modulation |
| CW / 270Hz,1KHz,2KHz | |
| OPTICAL INTERFACE | FC/PC standard - SC/PC optional |
| OPERATING TEMPERATURE RANGE | -10 ÷ +60 °C |
| STOCKING TEMPERATURE RANGE | -25 ÷ +70 °C |
| AUTOMATIC SHUT-OFF TIME | 10 min |
| BATTERY TIME | 60h |
| DIMENSIONS | 155x 76 x 38 mm |
| POWER SUPPLY | Alkaline batteries (3 AA 1.5V) |
| WEIGHT (g) | 300 |
